JT-216D fabric pleating machine

This automatic pleating machine utilizes high pressure and high heat to form and fix pleat patterns without extra assistant  procedures.

It can process fabric piece by piece or roll fabrics.

It is designed and manufactured to make traditional pleats like striped pleat, box pleat, bamboo leaf pleat and ripple-like pleat on  clothes for ladies skirts, tops, frocks, etc.

You can make more pleat patterns by exchanging different shape of knives and create your own design by changing or mix different  patterns variously.

Machine Dimensions(LxWxH)          3200x1600x1820 mm
Machine Weight 1,300 KG
Max Pleating Width1,650 mm
Max Pleating Speed100 pleats/min
Electric Consumption380V or 220V 3phase
Machine Capacity1.1KW (Main Motor) 9KW (Heaters)
