Ultrasonic horizontal cutting machine
Brief introduction：Ultrasonic cross cutting machine is mainly used for cutting towel cloth, eyeglass cloth, dust-free cloth, anti-static cloth, headrest and other products. The cutting width can be adjusted at will, and the minimum slitting is 15cm.
Detailed description
Application
Ultrasonic cross-cutting machine is mainly used for cutting towel cloth, glasses cloth, dust-free cloth, anti-static wipes, head cushion and other products. The cutting width can be adjusted at will, and the minimum cutting is 15cm.
There are various slitting styles such as: straight edge, zigzag edge, wave lace, small round edge, etc. The equipment has a wide variety of models, and we can tailor it to customers according to their needs.
parameter
| Operating Voltage | 220V |
| input power | 2KW |
| Maximum unwinding diameter | 400mm |
| Maximum working width | 200mm |
| Fastest cutting speed | 30m/min |
| Dimensions (L×W×H) | 1500*1500*1500mm |
| net weight | 600KG |
Features
- The cutting length of the ultrasonic crosscutting machine is controlled by liLC, the length can be set freely, the maximum length is 80cm;
- The cutting edge speed is controlled by a frequency conversion motor, and the speed is matched at will; the cutting width is adjustable at will, the minimum is 15cm;
- The equipment adopts aluminum alloy structure, which has high stability during high-speed operation, which effectively improves the durability of the machine and its service life;
- The tension of the unwinding fabric is controlled by mechanical tension; the feeding process is uniform, which improves the smoothness and cleanliness of the cut;
- Equipped with a counting device, which can realize the function of automatic shutdown at a fixed number
- Ultrasonic cutting has no burrs, scorching, and discoloration.
